Taishan digital catalog

Industrial Wheels Catalog

Current product images, dimensions, bearings, load capacities and model codes

Catalog index

Browse Product Series

Choose a product family below, then compare current configurations and technical data in catalog order. Every product title and specification links to its current website page.

Industrial Wheel Ranges Covered

The catalog includes rubber, thermoplastic rubber, polypropylene, polyurethane, nylon, cast iron and specialist industrial wheels. Depending on the series, tables may show plain bore, roller bearing, single ball bearing or two ball bearing options.

How to Compare Wheel Specifications

Confirm the tread material, wheel diameter, wheel width, hub length, hub bore, bearing and rated load. Floor condition, rolling noise, resistance to chemicals, temperature and manual or powered travel also affect the correct choice.

Information for a Quotation

Send the catalog code, required dimensions, bearing, load per wheel, application, operating environment and quantity. Include axle or hub drawings when a standard bore does not match the equipment.

Product chapter

Thermoplastic Rubber (TPR) Wheels

Browse Thermoplastic Rubber (TPR) Wheels. Thermoplastic rubber wheels combine a resilient tread with a thermoplastic construction; verify floor, temperature and.

3 product seriesBrowse product family

Thermoplastic Rubber (TPR) Wheels

TE Series Grey Thermoplastic Rubber Wheels

Roller Bearing Wheels

Wheel sizes: 80 / 100 / 125Load range: 90-150kg

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
80D32DTERX4012	Roller Bearing	80	32	40	12	90
100D32DTERX4012	Roller Bearing	100	32	40	12	100
125D40DTERX5015	Roller Bearing	125	40	50	15	150

Single Ball Bearing Wheels

Wheel sizes: 80 / 100 / 125Load range: 90-150kg

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
80D32DTEBA4208	Single Ball Bearing	80	32	42	8	90
100D32DTEBA4208	Single Ball Bearing	100	32	42	8	100
125D40DTEBA5210	Single Ball Bearing	125	40	52	10	150

Thermoplastic Rubber (TPR) Wheels

TP Series Grey Thermoplastic Rubber Wheels

Plain Bore Wheels

Wheel sizes: 75 / 100 / 125Load range: 75-100kg

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
75D30DTPPX3612	Plain Bore	75	30	36	12	75
100D32DTPPX3612	Plain Bore	100	32	36	12	100
125D32DTPPX3612	Plain Bore	125	32	36	12	100

Single Ball Bearing Wheels

Wheel sizes: 75 / 100 / 125Load range: 75-100kg

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
75D30DTPBB3708	Single Ball Bearing	75	30	37	8	75
100D32DTPBB3708	Single Ball Bearing	100	32	37	8	100
125D32DTPBB3708	Single Ball Bearing	125	32	37	8	100

Thermoplastic Rubber (TPR) Wheels

TR Series Grey Thermoplastic Rubber Wheels

Single Ball Bearing Wheels

Wheel sizes: 100 / 125 / 160 / 200Load range: 100-250kg

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
100D32DTRBA4208	Single Ball Bearing	100	32	42	8	100
125D32DTRBA5110	Single Ball Bearing	125	32	52	10	150
160D40DTRBA6212	Single Ball Bearing	160	40	62	12	200
200D40DTRBA6212	Single Ball Bearing	200	40	62	12	250

Roller Bearing Wheels

Wheel sizes: 100 / 125 / 160 / 200Load range: 100-250kg

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
100D32DTRRX4012	Roller Bearing	100	32	40	12	100
125D32DTRRX5015	Roller Bearing	125	32	50	15	150
160D40DTRRX6020	Roller Bearing	160	40	60	20	200
200D40DTRRX6020	Roller Bearing	200	40	60	20	250

Product chapter

Polypropylene (PP) Wheels

Browse Polypropylene (PP) Wheels. Polypropylene wheels provide a rigid thermoplastic option; compare bearing, dimensions, temperature and chemical exposure.

2 product seriesBrowse product family

Polypropylene (PP) Wheels

PP Series White Polypropylene Wheels

Roller Bearing Wheels

Wheel sizes: 80 / 100 / 125 / 150 / 160 / 200Load range: 80-300kg

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
80B34BPPRX4012	Roller Bearing	80	34	40	12	80
100B36BPPRX4012	Roller Bearing	100	36	40	12	120
125B40BPPRX5015	Roller Bearing	125	40	50	15	150
150B40BPPRX6020	Roller Bearing	150	40	60	20	200
160B40BPPRX6020	Roller Bearing	160	40	60	20	250
200B46BPPRX6020	Roller Bearing	200	46	60	20	300

Plain Bore Wheels

Wheel sizes: 80 / 100 / 125 / 150 / 160 / 200Load range: 80-300kg

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
80B34BPPPX4012	Plain Bore	80	34	40	12	80
100B36BPPPX4012	Plain Bore	100	36	40	12	120
125B40BPPPX5015	Plain Bore	125	40	50	15	150
150B40BPPPX6020	Plain Bore	150	40	60	20	200
160B40BPPPX6020	Plain Bore	160	40	60	20	250
200B46BPPPX6020	Plain Bore	200	46	60	20	300

Single Ball Bearing Wheels

Wheel sizes: 80 / 100 / 125Load range: 80-150kg

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
80B34BPPBA4208	Single Ball Bearing	80	34	42	8	80
100B36BPPBA4208	Single Ball Bearing	100	36	42	8	120
125B40BPPBA5210	Single Ball Bearing	125	40	52	10	150

Polypropylene (PP) Wheels

RE Series Grey Polypropylene Sandwich Wheels

Single Ball Bearing Wheels

Wheel sizes: 100 / 125Load range: 130-160kg

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
100B36REBA4208	Single Ball Bearing	100	36	42	8	130
125B36REBA5210	Single Ball Bearing	125	36	52	10	160

Roller Bearing Wheels

Wheel sizes: 100 / 125Load range: 130-160kg

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
100B36RERX4012	Roller Bearing	100	36	40	12	130
125B36RERX5015	Roller Bearing	125	36	50	15	160

Product chapter

Solid Rubber Wheels

Browse Solid Rubber Wheels. Solid rubber wheels provide a practical general-purpose tread; compare hardness, diameter, bearing and load for the application..

4 product seriesBrowse product family

Solid Rubber Wheels

BM Series Black Solid Rubber Wheels

View Roller Bearing Wheels

Roller Bearing Wheels

Wheel sizes: 80 / 100 / 125 / 150 / 160 / 180 / 200 / 250 / 300 / 350 / 400Load range: 50-475kg

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
80C30CBMRX4012	Roller Bearing	80	30	40	12	50
100C30CBMRX4012	Roller Bearing	100	30	40	12	75
125C37.5CBMRX5015	Roller Bearing	125	37.5	50	15	100
150C40CBMRX6020	Roller Bearing	150	40	60	20	135
160C40CBMRX6020	Roller Bearing	160	40	60	20	135
180C50CBMRX6020	Roller Bearing	180	50	60	20	205
200C50CBMRX6020	Roller Bearing	200	50	60	20	205
250C60CBMRX7525	Roller Bearing	250	60	75	25	295
300C60CBMRX7525	Roller Bearing	300	60	75	25	300
350C70CBMRX7525	Roller Bearing	350	70	80	25	300
400C75CBMRX9025	Roller Bearing	400	75	90	25	475

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
80C30CBPPX4012	Plain Bore	80	30	40	12	50
100C30CBPPX4012	Plain Bore	100	30	40	12	75
125C37.5CBPPX5015	Plain Bore	125	37.5	50	15	100
140C37.5CBPPX5015	Plain Bore	140	37.5	50	15	115
150C37.5CBPPX5015	Plain Bore	150	37.5	50	15	115
160C40CBPPX6020	Plain Bore	160	40	60	20	135
180C50CBPPX6020	Plain Bore	180	50	60	20	205
200C50CBPPX6020	Plain Bore	200	50	60	20	205
250C50CBPPX7525	Plain Bore	250	50	75	25	220
250C60CBPPX7525	Plain Bore	250	60	75	25	295
300C50CBPPX7525	Plain Bore	300	50	75	25	250

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
80C30CBPRX4012	Roller Bearing	80	30	40	12	50
100C30CBPRX4012	Roller Bearing	100	30	40	12	75
125C37.5CBPRX5015	Roller Bearing	125	37.5	50	15	100
140C37.5CBPRX5015	Roller Bearing	140	37.5	50	15	115
150C37.5CBPRX5015	Roller Bearing	150	37.5	50	15	115
160C40CBPRX6020	Roller Bearing	160	40	60	20	135
180C50CBPRX6020	Roller Bearing	180	50	60	20	205
200C50CBPRX6020	Roller Bearing	200	50	60	20	205
250C50CBPRX7525	Roller Bearing	250	50	75	25	220
250C60CBPRX7525	Roller Bearing	250	60	75	25	295
300C50CBPRX7525	Roller Bearing	300	50	75	25	250

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
180C50CBPdX6020	Two Ball Bearing	180	50	60	20	205
200C50CBPdX6020	Two Ball Bearing	200	50	60	20	205
250C60CBPDX7525	Two Ball Bearing	250	60	75	25	295
300C60CBPPX7525	Two Ball Bearing	300	50	75	25	250

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
80D30JGMRX4012	Roller Bearing	80	30	40	12	50
100D30JGMRX4012	Roller Bearing	100	30	40	12	75
125D37.5JGMRX5015	Roller Bearing	125	37.5	50	15	100
150D40JGMRX6020	Roller Bearing	150	40	60	20	135
160D40JGMRX6020	Roller Bearing	160	40	60	20	135
180D50JGMRX6020	Roller Bearing	180	50	60	20	205
200D50JGMRX6020	Roller Bearing	200	50	60	20	205
250D60JGMRX7525	Roller Bearing	250	60	75	25	295
300D60JGMRX7525	Roller Bearing	300	60	75	25	300
350D70JGMRX8025	Roller Bearing	350	70	80	25	300
400D75JGMRX9025	Roller Bearing	400	75	90	25	475

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
80D30CGPPX4012	Plain Bore	80	30	40	12	50
100D30CGPPX4012	Plain Bore	100	30	40	12	75
125D37.5CGPPX5015	Plain Bore	125	37.5	50	15	100
140D37.5CGPPX5015	Plain Bore	140	37.5	50	15	115
150D37.5CGPPX5015	Plain Bore	150	37.5	50	15	115
160D40CGPPX6020	Plain Bore	160	40	60	20	135
180D50CGPPX6020	Plain Bore	180	50	60	20	205
200D50CGPPX6020	Plain Bore	200	50	60	20	205
250D50CGPPX7525	Plain Bore	250	50	75	25	220
250D60CGPPX7525	Plain Bore	250	60	75	25	295
300D50CGPPX7525	Plain Bore	300	50	75	25	250

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
80D30CGPRX4012	Roller Bearing	80	30	40	12	50
100D30CGPRX4012	Roller Bearing	100	30	40	12	75
125D37.5CGPRX5015	Roller Bearing	125	37.5	50	15	100
140D37.5CGPRX5015	Roller Bearing	140	37.5	50	15	115
150D37.5CGPRX5015	Roller Bearing	150	37.5	50	15	115
160D40CGPRX6020	Roller Bearing	160	40	60	20	135
180D50CGPRX6020	Roller Bearing	180	50	60	20	205
200D50CGPRX6020	Roller Bearing	200	50	60	20	205
250D50CGPRX7525	Roller Bearing	250	50	75	25	220
250D60CGPRX7525	Roller Bearing	250	60	75	25	295
300D50CGPRX7525	Roller Bearing	300	50	75	25	250

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
180D50CGPDX6020	Two Ball Bearing	180	50	60	20	205
200D50CGPDX6020	Two Ball Bearing	200	50	60	20	205
250D60CGPDX7525	Two Ball Bearing	250	60	75	25	295
300D50CGPDX7525	Two Ball Bearing	300	50	75	25	250

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
125C37.5JMB(SH)RX5015	Roller Bearing	125	37.5	50	15	50
160C40JMB(SH)RX6020	Roller Bearing	160	40	60	20	70
200C50JMB(SH)RX6020	Roller Bearing	200	50	60	20	100
250C60JMB(SH)RX7525	Roller Bearing	250	60	75	25	160
260C85JMB(SH)RX7525	Roller Bearing	260	85	75	25	200

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
125C37.5CBP(SH)RX5015	Roller Bearing	125	37.5	50	15	50
160C40CBP(SH)RX6020	Roller Bearing	160	40	60	20	70
200C50CBP(SH)RX6020	Roller Bearing	200	50	60	20	100
250C60CBP(SH)RX7525	Roller Bearing	250	60	75	25	160
260C85CBP(SH)RX7525	Roller Bearing	260	85	75	25	200

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
125C37.5CBP(SH)PX5015	Plain Bore	125	37.5	50	15	50
160C40CBP(SH)PX6020	Plain Bore	160	40	60	20	70
200C50CBP(SH)PX6020	Plain Bore	200	50	60	20	100
250C60CBP(SH)PX7525	Plain Bore	250	60	75	25	160
260C85CBP(SH)PX7525	Plain Bore	260	85	75	25	200

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
250C60CBP(SH)DX7525	Two Ball Bearing	250	60	75	25	160
260C85CBP(SH)DX7525	Two Ball Bearing	260	85	75	25	200

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
80C38JEADX4015	Two Ball Bearing	80	38	40	15	150
100C40JEADX4015	Two Ball Bearing	100	40	40	15	200
125C40JEADX5015	Two Ball Bearing	125	40	50	15	250
125C50JEADX6020	Two Ball Bearing	125	50	60	20	270
140C44JEADX6020	Two Ball Bearing	140	44	60	20	270
150C50JEADX6020	Two Ball Bearing	150	50	60	20	400
160C50JEADX6020	Two Ball Bearing	160	50	60	20	400
180C50JEADX6020	Two Ball Bearing	180	50	60	20	450
200C50JEADX6020	Two Ball Bearing	200	50	60	20	500
250C50JEADX6020	Two Ball Bearing	250	50	60	20	650
300C60JEADX7525	Two Ball Bearing	300	60	75	25	800

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
80D38JEADX4015	Two Ball Bearing	80	38	40	15	150
100D40JEADX4015	Two Ball Bearing	100	40	40	15	200
125D40JEADX5015	Two Ball Bearing	125	40	50	15	250
125D50JEADX6020	Two Ball Bearing	125	50	60	20	270
140C44JEADX6020	Two Ball Bearing	140	44	60	20	270
150C50JEADX6020	Two Ball Bearing	150	50	60	20	400
160C50JEADX6020	Two Ball Bearing	160	50	60	20	400
180C50JEADX6020	Two Ball Bearing	180	50	60	20	450
200C50JEADX6020	Two Ball Bearing	200	50	60	20	500
250C50JEADX6020	Two Ball Bearing	250	50	60	20	650
300C60JEADX7525	Two Ball Bearing	300	60	75	25	800

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
160C50CEIDX6020	Two Ball Bearing	160	50	60	20	450
200C50CEIDX6020	Two Ball Bearing	200	50	60	20	550
250C50CEIDX9025	Two Ball Bearing	250	50	90	25	850
250C80CEIDX9025	Two Ball Bearing	250	80	90	25	1000
550C160CEIDX9030	Two Ball Bearing	550	160	90	30	2250

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
250C85JELDX7520	Two Ball Bearing	250	85	75	20	450
306C105JELDX7520	Two Ball Bearing	306	105	75	20	450
405C105JELDX9030	Two Ball Bearing	405	105	90	30	950
455C120JELDX9030	Two Ball Bearing	455	120	90	30	1090
525C140JELDX12045	Two Ball Bearing	525	140	120	45	1885

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
250D85JELDX7520	Two Ball Bearing	250	85	75	20	450
306D105JELDX7520	Two Ball Bearing	306	105	75	20	450
405D105JELDX9030	Two Ball Bearing	405	105	90	30	950
455D120JELDX9030	Two Ball Bearing	455	120	90	30	1090
525D140JELDX12045	Two Ball Bearing	525	140	120	45	1885

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
60C35CEPDX4012	Two Ball Bearing	60	35	40	12	100
80C36CEPDX4015	Two Ball Bearing	80	36	40	15	140
100C36CEPDX4015	Two Ball Bearing	100	36	40	15	180
100C50CEPDX6212	Two Ball Bearing	100	50	62	12	200
125C36CEPDX5015	Two Ball Bearing	125	36	50	15	230
125C50CEPDX6212	Two Ball Bearing	125	50	62	12	250
150C50CEPDX6020	Two Ball Bearing	150	50	60	20	350
160C42CEPDX6020	Two Ball Bearing	160	42	60	20	300
160C50CEPDX6020	Two Ball Bearing	160	50	60	20	400
200C45CEPDX6020	Two Ball Bearing	200	45	60	20	400
200C50CEPDX6020	Two Ball Bearing	200	50	60	20	500
250C50CEPDX6025	Two Ball Bearing	250	50	60	25	600

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
75C36CEPBA4208	Single Ball Bearing	75	36	42	8	110
80C35CEPBA4208	Single Ball Bearing	80	36	42	8	140
100C36CEPBA4208	Single Ball Bearing	100	36	42	8	180
125C36CEPBA5210	Single Ball Bearing	125	36	52	10	230
125C38CEPBA5210	Single Ball Bearing	125	38	52	10	250

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
80C35CEPRX4012	Roller Bearing	80	35	40	12	140
100C32CEPRX4012	Roller Bearing	100	32	40	12	160
100C36CEPRX4012	Roller Bearing	100	36	40	12	180
125C36CEPRX5015	Roller Bearing	125	36	50	15	230
125C38CEPRX5015	Roller Bearing	125	38	50	15	250
150C48CEPRX6020	Roller Bearing	150	48	60	20	320
160C48CEPRX6020	Roller Bearing	160	48	60	20	350
200C48CEPRX6020	Roller Bearing	200	48	60	20	450
250C50CEPRX6025	Roller Bearing	250	50	60	25	600

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
60A35CEPDX4012	Two Ball Bearing	60	35	40	12	100
80A36CEPDX4015	Two Ball Bearing	80	36	40	15	140
100A36CEPDX4015	Two Ball Bearing	100	36	40	15	180
100A50CEPDX6212	Two Ball Bearing	100	50	62	12	200
125A36CEPDX5015	Two Ball Bearing	125	36	50	15	230
125A50CEPDX6212	Two Ball Bearing	125	50	62	12	250
150A50CEPDX6020	Two Ball Bearing	150	50	60	20	350
160A42CEPDX6020	Two Ball Bearing	160	42	60	20	300
160A50CEPDX6020	Two Ball Bearing	160	50	60	20	400
200A45CEPDX6020	Two Ball Bearing	200	45	60	20	400
200A50CEPDX6020	Two Ball Bearing	200	50	60	20	500
250A50CEPDX6025	Two Ball Bearing	250	50	60	25	600

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
75A36CEPBA4208	Single Ball Bearing	75	36	42	8	110
80A35CEPBA4208	Single Ball Bearing	80	36	42	8	140
100A36CEPBA4208	Single Ball Bearing	100	36	42	8	180
125A36CEPBA5210	Single Ball Bearing	125	36	52	10	230
125A38CEPBA5210	Single Ball Bearing	125	38	52	10	250

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
80A35CEPRX4012	Roller Bearing	80	35	40	12	140
100A32CEPRX4012	Roller Bearing	100	32	40	12	160
100A36CEPRX4012	Roller Bearing	100	36	40	12	180
125A36CEPRX5015	Roller Bearing	125	36	50	15	230
125A38CEPRX5015	Roller Bearing	125	38	50	15	250
150A48CEPRX6020	Roller Bearing	150	48	60	20	320
160A48CEPRX6020	Roller Bearing	160	48	60	20	350
200A48CEPRX6020	Roller Bearing	200	48	60	20	450
250A50CEPRX6025	Roller Bearing	250	50	60	25	600

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
60D35CEPDX4012	Two Ball Bearing	60	35	40	12	100
80D36CEPDX4015	Two Ball Bearing	80	36	40	15	140
100D36CEPDX4015	Two Ball Bearing	100	36	40	15	180
100D50CEPDX6212	Two Ball Bearing	100	50	62	12	200
125D36CEPDX5015	Two Ball Bearing	125	36	50	15	230
125D50CEPDX6212	Two Ball Bearing	125	50	62	12	250
150D50CEPDX6020	Two Ball Bearing	150	50	60	20	350
160D42CEPDX6020	Two Ball Bearing	160	42	60	20	300
160D50CEPDX6020	Two Ball Bearing	160	50	60	20	400
200D45CEPDX6020	Two Ball Bearing	200	45	60	20	400
200D50CEPDX6020	Two Ball Bearing	200	50	60	20	500
250D50CEPDX6025	Two Ball Bearing	250	50	60	25	600

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
75D36CEPBA4208	Single Ball Bearing	75	36	42	8	110
80D35CEPBA4208	Single Ball Bearing	80	36	42	8	140
100D36CEPBA4208	Single Ball Bearing	100	36	42	8	180
125D36CEPBA5210	Single Ball Bearing	125	36	52	10	230
125D38CEPBA5210	Single Ball Bearing	125	38	52	10	250

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
80D35CEPRX4012	Roller Bearing	80	35	40	12	140
100D32CEPRX4012	Roller Bearing	100	32	40	12	160
100D36CEPRX4012	Roller Bearing	100	36	40	12	180
125D36CEPRX5015	Roller Bearing	125	36	50	15	230
125D38CEPRX5015	Roller Bearing	125	38	50	15	250
150D48CEPRX6020	Roller Bearing	150	48	60	20	320
160D48CEPRX6020	Roller Bearing	160	48	60	20	350
200D48CEPRX6020	Roller Bearing	200	48	60	20	450
250D50CEPRX6025	Roller Bearing	250	50	60	25	600

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
160C50CESDX6020	Two Ball Bearing	160	50	60	20	450
200C50CESDX6020	Two Ball Bearing	200	50	60	20	550
250C80CESDX9025	Two Ball Bearing	250	80	90	25	1000
300C75CESDX8530	Two Ball Bearing	300	75	85	30	1000
360C75CESDX9030	Two Ball Bearing	360	75	90	30	950
400C65CESDX7535	Two Ball Bearing	400	65	75	35	900
415C90CESDX10035	Two Ball Bearing	415	90	100	35	1150

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
160D50CESDX6020	Two Ball Bearing	160	50	60	20	450
200D50CESDX6020	Two Ball Bearing	200	50	60	20	550
250D80CESDX9025	Two Ball Bearing	250	80	90	25	1000
300D75CESDX8530	Two Ball Bearing	300	75	85	30	1000
360D75CESDX9030	Two Ball Bearing	360	75	90	30	950
400D65CESDX7535	Two Ball Bearing	400	65	75	35	900
415D90CESDX10035	Two Ball Bearing	415	90	100	35	1150

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
100D34CETRX4012	Roller Bearing	100	34	40	12	160
125D40CETRX5015	Roller Bearing	125	40	50	15	250
160D46CETDA6212	Roller Bearing	160	46	62	12	300
200D46CETRX6020	Roller Bearing	200	46	60	20	400
200D46CETDA6212	Roller Bearing	200	46	62	12	400

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
100D34CETBA4208	Single Ball Bearing	100	34	42	8	160
125D40CETBA5210	Single Ball Bearing	125	40	52	10	250

Code Number	Bearing	Wheel Diameter(mm)	Wheel Width(mm)	Hub Length(mm)	Hub Bore(mm)	Load Capacity(kg)
100A34CETRX4012	Roller Bearing	100	34	40	12	160
125A40CETRX5015	Roller Bearing	125	40	50	15	250
160A46CETDA6212	Roller Bearing	160	46	62	12	300
200A46CETRX6020	Roller Bearing	200	46	60	20	400
200A46CETDA6212	Roller Bearing	200	46	62	12	400
