Castor Specifications
Slide to the right to view all castor specifications
| Castor Number |  Wheel Diameter ( mm ) |  Tread of Width ( mm ) |  Size of Plate ( mm ) |  Plate Hole Center ( mm ) |  Plate Hole ( mm ) |  Offset ( mm ) |  Overall Height ( mm ) |  Load Capacity ( kg ) |
|---|---|---|---|---|---|---|---|---|
| 06P1S100C40JEADX4015 | 100 | 40 | 135x110 | 105x80 | 13.5x11 | 45 | 128 | 200 |
| 06P1S125C40JEADX5015 | 125 | 40 | 135x110 | 105x80 | 13.5x11 | 48 | 155 | 250 |
| 06P1S/S125C40JEADX5015 | 125 | 40 | 135x110 | 105x80 | 13.5x11 | 48 | 155 | 250 |
Castor Information
Wheel Tread Material
Elastic rubber
Wheel Centre Material
Aluminium
Castor Housing
Swivel
Mounting Type
Top Plate
Castor Bearing
Double ball bearings
Temperature Range
-20 to +60°C
Hardness of Tread
68°+5 Shore A
Threadguard
None
Color
Black
Description
Housing
pressed steel swivel fork, zinc-plated double ball race, sealed in the swviel head
Wheel
silvery casting-aluminium wheel centre shore a 68+5 black elastic rubber tread, two ball bearings
Applicable Terrain
Tile Floor
Resin Cement Floor
Asphalt Floor
Not Paved
Expanded Metal
Floor With Chips
