Load capacity 300-1500kg, suitable for heavy equipment.
Multiple sizes, ideal for a variety of industrial applications.
Diameter 75-125mm, suitable for indoor smooth floor.
Aceitamos todos os desafios e as suas necessidades são a nossa principal prioridade.
Large size 260mm, load capacity 150kg, suitable for outdoor cart.
Specially designed for shopping carts with multiple braking options.
Specially designed for hot environment applications up to 250°C.
Resistant to most chemicals, oils, greases, solvents and cleaning.
Wheel Tread
Thermoplastic rubber
Temperature
-20 to +60°C
Standard
EN 12532
Hardness of Tread
65° Shore A
Castor Description
Pressed steel swivel fork , zinc-plated double ball race , sealed in the swviel head, gery polypropylene wheel centre, Shore A 65, gery thermoplastic rubber tread, rollen bearing and single ball bearing, Benefits: Versatile use with excellent rolling characteristics. Low noise and vibration damping, non-marking.
You can use the button on the right to contact us for a quote at a good price.Or discuss your needs.
Swipe right to see the full table
| Castor Number |  Bearing Type |   Wheel Diameter & Width of Tread ( mm ) |  Size of Plate ( mm ) |  Plate Hole Center ( mm ) |  Plate Hole ( mm ) |  Overall Height ( mm ) |  Load Capacity ( kg 4km/h ) |
|---|---|---|---|---|---|---|---|
| 07P1F80D32DTEBA |  | 80x32 | 102x87 | 80x60 | 11x9 | 100 | 90 |
| 07P1F80D32DTERX |  | ||||||
| 07P1F100D32DTEBA | | 100x32 | 102x87 | 80x60 | 11x9 | 125 | 100 |
| 07P1F100D32DTERX | | ||||||
| 07P1F125D40DTEBA | | 125x40 | 102x87 | 80x60 | 11x9 | 155 | 150 |
| 07P1F125D40DTERX | |
Tile Floor
Resin Cement Floor
