Castor Specifications
Slide to the right to view all castor specifications
Castor Number | Bearing Type | Wheel Diameter & Width of Tread ( mm ) | Size of Plate ( mm ) | Plate Hole Center ( mm ) | Plate Hole ( mm ) | Overall Height ( mm ) | Load Capacity ( kg 4km/h ) |
---|---|---|---|---|---|---|---|
07P1F100D36DSTBA | 100x36 | 102x87 | 80x60 | 13.5x11 | 125 | 130 | |
07P1F100D36DSTRX | |||||||
07P1F125D36DSTBA | 125x36 | 102x87 | 80x60 | 13.5x11 | 155 | 160 | |
07P1F125D36DSTRX |
Castor Information
Wheel Tread Material
Polypropylene sandwich
Wheel Centre Material
Polypropylene
Castor Housing
Fixed
Mounting Type
Top Plate
Castor Bearing
Single ball bearing
Temperature Range
-20 to +60°C
Hardness of Tread
75° Shore A
Threadguard
None
Color
Grey
Description
Pressed steel swivel fork, zinc-plated double ball race, sealed in the swviel head, grey polypropylene wheel tread, grey thermoplastic rubber and grey polypropylene wheel centre, offers a choice of needle roller bearings and through bearings, Suitable for any terrain, Every user and application has different needs. Let us know how we can help you to become a satisfied customer.
Applicable Terrain
Tile Floor
Resin Cement Floor
