Castor Specifications
Slide to the right to view all castor specifications
Castor Number | Bearing Type | Wheel Diameter & Width of Tread ( mm ) | Size of Plate ( mm ) | Plate Hole Center ( mm ) | Plate Hole ( mm ) | Overall Height ( mm ) | Load Capacity ( kg 4km/h ) |
---|---|---|---|---|---|---|---|
07P1F80C38JEADX | 80x38 | 102x87 | 80x60 | 11x9 | 100 | 150 | |
07P1F100C40JEADX | 100x40 | 102x87 | 80x60 | 11x9 | 125 | 180 | |
07P1F125C40JEADX | 125x40 | 102x87 | 80x60 | 11x9 | 155 | 200 | |
07P1F160C50JEADX | 160x50 | 135x114 | 105x80 | 13.5x11 | 190 | 300 | |
07P1F200C50JEADX | 200x50 | 135x114 | 105x80 | 13.5x11 | 235 | 300 | |
07P1F250C50JEADX | 250x50 | 135x114 | 105x80 | 13.5x11 | 290 | 400 |
Castor Information
Wheel Tread Material
Elastic rubber
Wheel Centre Material
Aluminium
Castor Housing
Fixed
Mounting Type
Top Plate
Castor Bearing
Double ball bearings
Temperature Range
-20 to +80°C
Hardness of Tread
68°+5 Shore A
Threadguard
None
Color
Black
Description
Pressed steel swivel fork, Integrated die casting moulding, no swivel, Shore A 68+5, black elastic rubber wheel tread, casting aluminium wheel centre, double ball bearings, diameter 80mm to 250mm, load capacity 150kg to 400kg, Applications: industrial trolleys, factory material handling, waste containers, transport containers, medium-sized rolling containers, tool carts, warehouse trolleys.
Applicable Terrain
Tile Floor
Resin Cement Floor
Asphalt Floor
Not Paved
Expanded Metal
Floor With Chips
