Castor Specifications
Slide to the right to view all castor specifications
| Castor Number |  Bearing Type |   Wheel Diameter & Width of Tread ( mm ) |  Size of Plate ( mm ) |  Plate Hole Center ( mm ) |  Plate Hole ( mm ) |  Overall Height ( mm ) |  Load Capacity ( kg 4km/h ) |
|---|---|---|---|---|---|---|---|
| 07P1F80A35CEPRX |  | 80x35 | 102x87 | 80x60 | 11x9 | 100 | 100 |
| 07P1F100A36CEPRX | | 100x36 | 102x87 | 80x60 | 11x9 | 125 | 150 |
| 07P1F125A36CEPRX | | 125x36 | 102x87 | 80x60 | 11x9 | 155 | 200 |
| 07P1F160A48CEPRX | | 160x48 | 135x114 | 105x80 | 13.5x11 | 190 | 300 |
| 07P1F200A48CEPRX | | 200x48 | 135x114 | 105x80 | 13.5x11 | 235 | 300 |
| 07P1F250A50CEPRX | | 250x50 | 135x114 | 105x80 | 13.5x11 | 290 | 400 |
Castor Information
Wheel Tread Material
Elastic rubber
Wheel Centre Material
Polyamide
Castor Housing
Fixed
Mounting Type
Top Plate
Castor Bearing
Roller bearing
Temperature Range
-20 to +80°C
Hardness of Tread
68°+5 Shore A
Threadguard
None
Color
Blue
Description
Pressed steel swivel fork, Integrated die casting moulding, no swivel, Shore A 68+5, blue elastic rubber wheel tread, black nylon wheel centre, roller bearings, diameter 80mm to 250mm, load capacity 100kg to 400kg, Benefits: Versatile use with excellent rolling characteristics. Low noise and vibration damping,
Applicable Terrain
Tile Floor
Resin Cement Floor
Asphalt Floor
Not Paved
Expanded Metal
Floor With Chips
