Castor Specifications
Slide to the right to view all castor specifications
CastorNumber | Bearing Type | Wheel Diameter & Width of Tread ( mm ) | Size of Plate ( mm ) | Plate Hole Center ( mm ) | Plate Hole ( mm ) | Offset ( mm ) | Overall Height ( mm ) | Load Capacity ( kg 4km/h ) |
---|---|---|---|---|---|---|---|---|
03P1RB80E32JUIDX | 80x32 | 105x80 | 80x60 | 11x9 | 40 | 120 | 250 | |
03P1RB100E32JUIDX | 100x32 | 105x80 | 80x60 | 11x9 | 40 | 130 | 350 | |
03P1RB125E50JUIDX | 125x50 | 135x110 | 105x80 | 13.5x11 | 50 | 178 | 660 | |
03P1RB150E50JUIDX | 150x50 | 135x110 | 105x80 | 13.5x11 | 53 | 210 | 800 | |
03P1RB160E50JUIDX | 160x50 | 135x110 | 105x80 | 13.5x11 | 53 | 215 | 800 | |
03P1RB200E50JUIDX | 200x50 | 135x110 | 105x80 | 13.5x11 | 55 | 245 | 800 |
Castor Information
Wheel Tread Material
Polyurethane
Wheel Centre Material
Iron
Castor Housing
Total Brake
Mounting Type
Top Plate
Castor Bearing
Double ball bearings
Temperature Range
-20 to +60°C
Hardness of Tread
94° Shore A
Threadguard
None
Color
Yellow
Description
Swivel castors with total brake, housing made of heavy pressed steel, bright zinc plate, precision ball bearing swivel head sealed, wheel axle with nut, plate fitting, castor wheel tread grey thermoplastic polyurethane, Shore A 94, double ball bearings, wheel center made of casting iron, wheel diameter 80mm to 250mm, load capacity 250kg to 800kg. This heavy duty castor is perfect for mounting on high duty carts or equipment, industrial trolleys, material handling carts, shipping containers, metalworking equipment, tool carts, warehouse trolleys, contact a sales manager right away for a discounted price.
Applicable Terrain
Tile Floor
Resin Cement Floor
