Hight Quality Heavy Duty Yellow Polyurethane Swivel Castor Wheels from Industry Leading Manufacturer

Castor Specifications

Slide to the right to view all castor specifications

CastorNumber	Wheel Diameter & Width of Tread ( mm )	Size of Plate ( mm )	Plate Hole Center ( mm )	Plate Hole ( mm )	Offset ( mm )	Overall Height ( mm )	Load Capacity ( kg 4km/h )
23P1S125E50JUIDX	125x50	135x110	105x80	13.5x11	50	170	660
23P1S150E50JUIDX	150x50	135x110	105x80	13.5x11	57	200	800
23P1S160E50JUIDX	160x50	135x110	105x80	13.5x11	57	205	900
23P1S200E50JUIDX	200x50	135x110	105x80	13.5x11	65	245	1200
23P1S250E50JUIDX	250x50	135x110	105x80	13.5x11	80	305	1440
23P1S250E80JUIDX	250x80	135x110	105x80	13.5x11	80	305	1800

Castor Information

Wheel Tread Material

Polyurethane

Wheel Centre Material

Iron

Castor Housing

Swivel

Mounting Type

Top Plate

Castor Bearing

Double ball bearings

Temperature Range

-20 to +60°C

Hardness of Tread

94° Shore A

Threadguard

None

Color

Yellow

Description

Swivel castors, housing made of heavy pressed steel, bright zinc plate, precision ball bearing swivel head sealed, wheel axle with nut, plate fitting, castor wheel tread green elastic polyurethane, Shore A 94, double ball bearings, wheel center made of aluminum, wheel diameter 125mm to 250mm, load capacity 660kg to 1800kg. Stringent quality testing process ensures the quality of supplied heavy duty castors, rest assured to purchase our casters in bulk.
