Best Heavy Duty Polyurethane Swivel Castor Wheels Manufacturer

Castor Specifications

Slide to the right to view all castor specifications

CastorNumber	Wheel Diameter & Width of Tread ( mm )	Size of Plate ( mm )	Plate Hole Center ( mm )	Plate Hole ( mm )	Offset ( mm )	Overall Height ( mm )	Load Capacity ( kg 4km/h )
23P1S125E50JUADX	125x50	135x110	105x80	13.5x11	50	170	500
23P1S150E50JUADX	150x50	135x110	105x80	13.5x11	57	200	500
23P1S160E50JUADX	160x50	135x110	105x80	13.5x11	57	205	800
23P1S200E50JUADX	200x50	135x110	105x80	13.5x11	65	245	800
23P1S250E60JUADX	250x60	135x110	105x80	13.5x11	80	305	1000

Castor Information

Wheel Tread Material

Polyurethane

Wheel Centre Material

Aluminium

Castor Housing

Swivel

Mounting Type

Top Plate

Castor Bearing

Double ball bearings

Temperature Range

-20 to +60°C

Hardness of Tread

94° Shore A

Threadguard

None

Color

Yellow

Description

Swivel castors, housing made of heavy pressed steel, bright zinc plate, precision ball bearing swivel head sealed, wheel axle with nut, plate fitting, castor wheel tread green elastic polyurethane, Shore A 94, double ball bearings, wheel center made of aluminum, wheel diameter 125mm to 250mm, load capacity 500kg to 1000kg. Every user and application has different needs. Let us know how we can help you to become a satisfied customer.

Applicable Terrain
