Popular Heavy Weight Yellow Polyurethane Fixed Castor Wheels Company

Castor Specifications

Slide to the right to view all castor specifications

Castor Number	Wheel Diameter & Width of Tread ( mm )	Size of Plate ( mm )	Plate Hole Center ( mm )	Plate Hole ( mm )	Overall Height ( mm )	Load Capacity ( kg 4km/h )
03P1F80E32JUIDX	80x32	105x85	80x60	11x9	120	250
03P1F100E32JUIDX	100x32	105x85	80x60	119	130	350
03P1F125E50JUIDX	125x50	135x114	105x80	13.5x11	178	660
03P1F150E50JUIDX	150x50	135x114	105x80	13.5x11	210	800
03P1F160E50JUIDX	160x50	135x114	105x80	13.5x11	215	800
03P1F200E50JUIDX	200x50	135x114	105x80	13.5x11	245	800
03P1F250E50JUIDX	250x50	135x114	105x80	13.5x11	297	1000

Castor Information

Wheel Tread Material

Polyurethane

Wheel Centre Material

Iron

Castor Housing

Fixed

Mounting Type

Top Plate

Castor Bearing

Double ball bearings

Temperature Range

-20 to +60°C

Hardness of Tread

94° Shore A

Threadguard

None

Color

Yellow

Description

Fixed castors, housing made of heavy pressed steel, bright zinc plate, precision ball bearing swivel head sealed, wheel axle with nut, plate fitting, castor wheel tread green elastic polyurethane, Shore A 85, double ball bearings, wheel center made of aluminum, wheel diameter 160mm and 200mm, load capacity 250kg to 1000kg. Every user and application has different needs. Let us know how we can help you to become a satisfied customer.

Applicable Terrain
