Castor Specifications
Slide to the right to view all castor specifications
| Castor Number |  Bearing Type |   Wheel Diameter & Width of Tread ( mm ) |  Size of Plate ( mm ) |  Plate Hole Center ( mm ) |  Plate Hole ( mm ) |  Overall Height ( mm ) |  Load Capacity ( kg 4km/h ) |
|---|---|---|---|---|---|---|---|
| 23P1F160C50CESDX |  | 160x50 | 135x110 | 105x80 | 13.5x11 | 205 | 450 |
| 23P1F200C50CESDX | | 200x50 | 135x110 | 105x80 | 13.5x11 | 245 | 550 |
| 23P1F250C80CESDX | | 250x80 | 135x110 | 105x80 | 13.5x11 | 305 | 1000 |
Castor Information
Wheel Tread Material
Elastic rubber
Wheel Centre Material
Steel welding
Castor Housing
Fixed
Mounting Type
Top Plate
Castor Bearing
Double ball bearings
Temperature Range
-20 to +80°C
Hardness of Tread
68°+5 Shore A
Threadguard
None
Color
Black
Description
Fixed castor, housing made of heavy pressed steel, bright zinc plate, castor wheel tread elastic rubber, shore A 68+5, wheel center made of pressed steel, double ball bearings, wheel diameter 160mm to 250mm, load capacity 450kg to 1000kg. Our quality is creating an easier work-life for the user of the wheel.
Applicable Terrain
Tile Floor
Resin Cement Floor
Asphalt Floor
Not Paved
Expanded Metal
Floor With Chips
